Rinox Infinity
Adjustable compensated pressure reducing valve, diaphragm operated
Serie 4291
Adjustable compensated pressure reducing valve with FF - PN40 connections, diaphragm operated, double seat, made of stainless steel, with anti-water hammer function. Suitable for water conveyance.
| Nickel-plated brass body. |
| Stainless steel AISI 303. |
| Elastomer seals. |
| Threaded connections FF UNI-EN-ISO 228. |
| Pressure gauge holder connection F 1/4". |
| Nominal pressure 40 Bar |
| Max upstream pressure 25 Bar |
| Max operating temperature 80 °C |
Download
Certifications:
DHW
First reduction pressure reducing valve with FF connections - pn 40
| Code | Size | Box | Carton | Cat. | € |
| 42910480 | G 1/2" | 1 | 6 | 06.01 | ||42910480_LastPrice|| |
| 42910500 | - | 1 | 6 | 06.01 | ||42910500_LastPrice|| |
outlet adjustment 6 ÷ 10 Bar
First reduction pressure reducing valve: this reduces upstream pressures near a value of 25 bar in compliance with the reduction ratio recommended by RBM.
